Steam generator 100 200 300 500 kg biomass pellet sawdust boiler
$16,453.04
Request a quote / bulk pricing
Buying for a business or need several units? Send us the quantity and destination and we will reply with a quote.
Description
SPECIFICATIONS
Brand Name: NONE
Feed water temperature: 20 ℃
High-concerned chemical: none
Material: Rubber
Origin: Mainland China
Structure: fire pipe
Type: Other
fuel: Wood pellet biomass coal
material: stainless steel
pressure: low pressure
purpose: industry
steam temperature: 171 ℃
thermal efficiency: 98%
type: VERTICAL
water volume: 29L
Product Description
Steam Generator 100kg 200kg 300kg 500 kg Biomass Pellet Wood Chips Boiler
Technical Parameters
|
Boiler Type
|
LSG
0.1
|
LSG
0.2
|
LSG
0.3
|
LSG
0.5
|
LSG
0.7
|
LSG
1.0
|
LSG
1.5
|
LSG
2.0
|
|||||||
|
Rated steam pressure(MPa)
|
0.4/0.7/1.0
|
|
|
|
|
|
|
|
|||||||
|
Rated steam temperature(℃)
|
152/170/184
|
|
|
|
|
|
|
|
|||||||
|
Feed water temperature(℃)
|
20
|
|
|
|
|
|
|
|
|||||||
|
Thermal efficiency(%)
|
≥83%
|
|
|
|
|
|
|
|
|||||||
|
Voltage(V)
|
220
|
220
|
220
|
220
|
380
|
380
|
380
|
380
|
|||||||
|
Biomass consumption(Kg/h)
|
15
|
39
|
58.5
|
97.5
|
136.5
|
195
|
292.5
|
390
|
|||||||
|
Coal consumption(Kg/h)
|
10
|
27
|
36
|
54
|
72
|
109
|
163
|
218
|
|||||||
|
Transport reference weight(kg）
|
800
|
1200
|
1400
|
1800
|
2200
|
2500
|
3600
|
5600
|
|||||||
Additional information
| Weight | 66.139 lbs |
|---|---|
| Color | LSG-Max. 4t h |
